Bosean K-G60 O2 Industrial Fixed gas detector Probe

Features:

• Five units can be switched at will, PPM, %VOL, mg/m3, umol/mol, 10^-6

• Output a variety of signals with a transmission distance of 1km,. Standard 4-20mA signal, 433MHz wireless transparent transmission function is optional, Standard RS485 signal, Dual relay passive signal output.

Specification：

• Product type：K-G60 fixed gas detector/transmitter

• Explosion proof grade：Exd ⅡC T6 Gb

• Response time：≦20S

• Power supply：DC24V±15%

• Working temperature：-20℃～50℃

• Output current：4-20mA

• Working humidity：0-95%RH

• Contact output：Free contact output, max power 1kW

• Single input：4~20mA and RS485

• Installation method：Wall mounted, pipe mounted, flow-through, pump suction

• Shell material：Aluminum

• Dimensions：177.5x127.5x104mm（L×W×H）
